DMM Alloy Offsets protect irregular and flared cracks that regular nuts cannot. Every size of Alloy Offset has a robust 12kN strength rating. The wires they are mounted on are set into a recess to reduce wear, while larger sizes have holes that reduce weight. Use in conjunction with Wallnuts for comprehensive all season crack protection.
| Product Name |
Product Code |
Color |
Weight |
Certification |
Strength |
Range |
NSN Code |
| HB Alloy Offset 7 |
A1817AA |
Gold |
27g |
EN 12270:2013 |
12kN |
12.0 / 15.1mm |
|
| HB Alloy Offset 8 |
A1818AA |
Blue |
30g |
EN 12270:2013 |
12kN |
13.5 / 17.9mm |
|
| HB Alloy Offset 9 |
A1819AA |
Red |
37g |
EN 12270:2013 |
12kN |
17.1 / 21.4mm |
|
| HB Alloy Offset 10 |
A1820AA |
Grey |
45g |
EN 12270:2013 |
12kN |
19.4 / 25.1mm |
|
| HB Alloy Offset 11 |
A1821AA |
Turquoise |
56g |
EN 12270:2013 |
12kN |
23.2 / 30.0mm |
|
| HB Alloy Offset 7-11 |
A1817/21AA |
Assorted |
195g |
EN 12270:2013 |
12kN |
12.0 - 30.0mm |
|
| HB Alloy Offset 7 |
A1817MG |
Matt Grey |
27g |
EN 12270:2013 |
12kN |
12.0 / 15.1mm |
|
| HB Alloy Offset 8 |
A1818MG |
Matt Grey |
30g |
EN 12270:2013 |
12kN |
13.5 / 17.9mm |
|
| HB Alloy Offset 9 |
A1819MG |
Matt Grey |
37g |
EN 12270:2013 |
12kN |
17.1 / 21.4mm |
|
| HB Alloy Offset 10 |
A1820MG |
Matt Grey |
45g |
EN 12270:2013 |
12kN |
19.4 / 25.1mm |
|
| HB Alloy Offset 11 |
A1821MG |
Matt Grey |
56g |
EN 12270:2013 |
12kN |
23.2 / 30.0mm |
|
| HB Alloy Offset 7-11 |
A1817/21MG |
Matt Grey |
195g |
EN 12270:2013 |
12kN |
12.0 - 30.0mm |
8465-99-877-8423 |
