The Phantom is Helix's lightest locking carabiner at just 42 grams. Despite its minimal weight, Helix has ensured that it is still usable in all situations - with gloves, in the wet and the cold. It is also strong across every axis (24kN major axis and 9kN minor axis) and has a clean nose that prevents snagging. The locker to carry when every gram counts. Very light, very strong and very useable.
The carabiner comes as standard with a matt grey anodized finish, but can also be supplied with a matt black anodized finish or with more specialist Ceracote finishes in a range of tactical colors from artic white to desert coyote. The Ceracote coatings are also available with a reduced IR signature.
| Product Name |
Product Code |
Color |
MBS (Major Axis) |
MBS (Minor Axis) |
MBS (Gate Open) |
Dimensions |
Weight |
Gate Opening (X) |
Certification |
NSN Code |
| Phantom Screwgate |
A312 |
Titanium/Lime |
24kN |
9kN |
9kN |
54 x 94mm |
42g |
15mm |
EN362:2004 B, EN12275:2013 B, UIAA121:2009 |
|
| Phantom Screwgate |
A312MG |
Matt Grey |
24kN |
9kN |
9kN |
54 x 94mm |
42g |
15mm |
EN 362:2004 B, EN 12275:2013 B |
8465-99-671-3875 |
| Phantom Screwgate |
A312RD-MG |
Red Back/ Matt Grey Thimble and Gate |
24kN |
9kN |
9kN |
54 x 94mm |
42g |
15mm |
EN 362:2004 B, EN 12275:2013 B |
|
| Phantom Screwgate |
A312LG |
Lime |
24kN |
9kN |
9kN |
54 x 94mm |
42g |
15mm |
EN362:2004 B, EN12275:2013 B |
|
| Phantom Screwgate |
A312OR |
Orange |
24kN |
9kN |
9kN |
54 x 94mm |
42g |
15mm |
EN362:2004 B, EN12275:2013 B |
|
