- Individually tested to meet OSHA standard 1910.269
- Equipped with toolless couplers for quick assembly and easy storage.
- The product includes both 9' and 12.5' length options for high flexibility.
- Shall the operator decide to tether the MADSAW, a tether point is attached at the rear.
- The X-Torq® engine design reduces harmful exhaust emissions by up to 60% and increases fuel efficiency by up to 20%.
- Robust magnesium clutch housing for tough professional use, ensuring a long service life.
- Removes air from carburetor and fuel system for easy starting.
- Stop switch automatically resets to the ON position for easier starting.
* Returns will NOT be accepted for any units that have been gassed or oiled. Contact customer service for help returning any unused items or for information relating to warranty claims.
| Engine | |
| Power output | 1.36 hp |
| Cylinder displacement | 1.55 cu.inch |
| Maximum power speed | 8,500 rpm |
| Idling speed | 3,000 rpm |
| Torque, max. | 1.2 Nm |
| Torque, max. at rpm | 6,000 rpm |
| Clutch engagement speed (±120) | 3,850 rpm |
| Fuel consumption | 395 g/kWh |
| Spark plug | NGK BPMR8Y |
| Equipment | |
| Bar length (inch) | 12 in |
| Chain type | S93G |
| Dimensions | |
| Weight (excl. cutting equipment) | 16.4 lbs |
| Lubricant | |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Sound and Noise | |
| Sound power level, guaranteed (LWA) | 111 dB(A) |
| Sound power level, measured | 107 dB(A) |
| Sound pressure level at operators ear | 91 dB(A) |
