Mesh is designed to optimize and repair itself, constantly seeking the best connection and automatically establishing a new one when a device becomes disconnected. Two different Mesh modes are available in the Cast system: Open Mesh and Group Mesh. Open Mesh allows many users to connect within an effective range of 1.1 km (0.7 mi), providing a wide-reaching network. Group Mesh is designed for private sessions, accommodating up to 24 participants.
GENERAL
Dimensions:
Headset: 136 mm x 200 mm x 102 mm (5.3 in x 7.8 x 4.0 in)
Speaker Driver Unit: 32 mm (1.3 in) - thickness 7.1 mm (0.3 in)
Boom Microphone: length - 70 mm (2.7 in)
Weight:
Over-the-Head: 474 g (16.7 oz)
Temperature:
Operating Temperature: -20°C ~ +60°C
Storage Temperature: 15°C ~ +60°C
Charging Temperature: 0˚C – 45˚C
NOISE REDUCTION RATING
Over-the-Head Earmuff Type:
NRR (ANSI S3.19-1974, US) - 28 dB
SNR (EN 352-1:2020, EU) - 34
SLC80 (AS/NZS 1270 Class 5, AUS/NZ) - 33 dB
AUDIO
Noise Cancellation:
Advanced Noise Control™
Codec:
Built-in SBC Codec
MESH NETWORK
Mesh 2.0 Intercom™ Technology
BLUETOOTH
Bluetooth 4.1
Headset Profile (HSP)
Hands-Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Audio Video Remote Control Profile (AVRCP)
INTERCOM
Working Distance:
Up to 1.1 km (0.7 miles) in open space*
*Can extend up to 4.4 km (2.8 miles) between a minimum of 6 users
BATTERY
Talk Time:
Up to 9 hours (with included Lithium Polymer rechargeable battery, talk time may vary if using 3 x AAA batteries)
Charging Time:
2.5 hours
Quick Charge:
20 minutes of charging equals 3 hours Mesh Intercom
Type:
Lithium Polymer Battery
Capacity:
1,100 mAh
CERTIFICATES
CE, FCC, IC, KC
